甘蓝型油菜BnMYB80基因的生物信息学分析

doi:10.11983/CBB16006

摘要/Abstract

摘要： 在高等植物花药发育和花粉形成中, MYB转录因子起着非常重要的作用, 其中MYB80是参与绒毡层发育及引起雄性不育的重要转录因子。该研究以拟南芥(Arabidopsis thaliana) AtMYB80为参考序列, 通过BLAST比对分析, 在白菜(Brassica rapa)、甘蓝(B. oleracea)和甘蓝型油菜(B. napus)中分别获得MYB80基因的2、2和6个同源序列, 运用生物信息学方法对其核苷酸序列及编码的氨基酸序列进行组成成分、亚细胞定位、磷酸化位点、疏水性/亲水性、蛋白质二级、三级结构和功能域分析。结果表明, MYB80转录因子亚细胞定位于细胞核, 具有多个不同的磷酸化位点, 肽链表现为亲水性; 二级、三级结构预测显示, MYB80蛋白以α-螺旋和无规则卷曲为主要结构元件; 保守结构域分析表明, 其N端具有2个串联的SANT功能域, 属于R2R3型MYB转录因子。多重序列比对和进化树分析结果表明, 甘蓝型油菜与白菜、甘蓝的序列相似性大于92%, 且MYB80转录因子的功能结构域具有较高的同源性和较强的序列保守性。该研究结果对深入解析甘蓝型油菜MYB80的生物学功能及育性调控的分子机理具有重要意义, 为甘蓝型油菜杂种优势利用提供了依据。

关键词: 生物信息学, 甘蓝型油菜, MYB80, 花粉发育, 绒毡层

Abstract: MYB transcription factors play a key role in anther development and pollen formation in higher plants, and MYB80 is an important transcription factor involved in the development of tapetum and initiation of male sterility. In this study, we performed BLASTN and TBLASTX searches of the Arabidopsis thaliana MYB80 (AtMYB80) amino acid sequences against the published database and identified 2, 2 and 6 homologous sequences of MYB80 gene in Brassica rapa, B. oleracea and B. napus, respectively. The composition of nucleic acid sequence and amino acid sequences, subcellular localization, phosphorylation sites, hydrophilicity and hydrophobicity, secondary and tertiary structure of protein, conserved domains of the MYB80 were predicted and analyzed by bioinformatics tools and resources from the Internet. The results showed that the MYB80 transcription factors are located in the nucleus by analyzing subcellular localization, with a number of different phosphorylation sites, and the peptide chains are hydrophilia. The predicted secondary structure and tertiary structure showed that the main structural elements of the MYB80 protein were α helix and random coil. Conserved domain analysis indicated that the MYB80 transcription factor belongs to the MYB-R2R3 type transcription factor, with 2 tandem SANT domains in the N-terminal sequence. The multiple sequence ratio and phylogenetic tree were constructed with MYB80 proteins from different plants; similarity among B. napus and B. rapa, and B. oleracea was more than 92%, and the conserved functional domains had high homology and strong sequence conservation. These results are helpful for resolving the biological functions of MYB80 and the molecular mechanism of sterility regulation and lay a foundation for the heterosis utilization in B. napus.

Key words: bioinformatics, Brassica napus, MYB80, pollen development, tapetum

贾乐东, 李施蒙, 许代香, 曲存民, 李加纳, 王瑞. 甘蓝型油菜BnMYB80基因的生物信息学分析. 植物学报, 2016, 51(5): 620-630.

Jia Ledong, Li Shimeng, Xu Daixiang, Qu Cunmin, Li Jiana, Wang Rui. Bioinformatics Analysis of BnMYB80 Genes in Brassica napus . Chinese Bulletin of Botany, 2016, 51(5): 620-630.

导出引用管理器 EndNote|Ris|BibTeX

链接本文: https://www.chinbullbotany.com/CN/10.11983/CBB16006

https://www.chinbullbotany.com/CN/Y2016/V51/I5/620

图/表 7

参考文献 39

1	陈凤祥, 胡宝成, 李强生, 张曼琳 (1993). 甘蓝型油菜细胞核雄性不育材料9012A的发现与初步研究. 北京农业大学学报 9, 57-61.
2	邓志刚, 金樑, 李晶, 王文斌, 杨龙, 王晓娟 (2013). MYB类转录因子对花药和花粉发育的调控途径. 西北植物学报 33, 850-856.
3	方子君, 石其龙, 杨仲南, 张森 (2008). 水稻OsMS2基因在花药发育中的功能分析. 植物学通报 25, 665-672.
4	郭弘光, 吴繁花 (2012). MYB转录因子功能与调控研究进展. 安徽农业科学 40, 10381-10383,10516.
5	侯国佐, 王华, 张瑞茂 (1990). 甘蓝型油菜细胞核雄性不育材料117A的遗传研究. 中国油料 2, 7-10.
6	胡胜武, 于澄宇, 赵惠贤, 路明 (2002). 甘蓝型油菜显性核不育材料Shaan-GMS纯合两型系803AB的选育. 西北农业学报 11, 25-27.
7	李树林, 周志疆, 周熙荣 (1993). 甘蓝型油菜隐性核不育系S45AB的遗传. 上海农业学报 9, 1-7.
8	刘琪迩, 杜坤, 王幼平 (2015). 油菜细胞质雄性不育与育性恢复机理的研究进展. 生物技术通报 31, 15-22.
9	刘淑娟, 朱祺, 幸学俊, 王碧琴, 余发新, 周华 (2014). 植物雄性不育影响因素研究进展. 中国农学通报 30, 46-50.
10	宋来强, 傅廷栋, 杨光圣, 涂金星, 马朝芝 (2005). 1对复等位基因控制的油菜(Brassica napus)显性核不育系609AB的遗传验证. 作物学报 31, 869-875.
11	孙超才, 赵华, 王伟荣, 李延莉, 钱小芳, 方光华 (2002). 甘蓝型油菜隐性核不育系20118A的遗传与利用探讨. 中国油料作物学报 24, 1-4.
12	王超, 安学丽, 张增为, 杨青, 饶力群, 陈信波, 方才臣, 万向元 (2013). 植物隐性核雄性不育基因育种技术体系的研究进展与展望. 中国生物工程杂志 33, 124-130.
13	王瑞, 李加纳, 唐章林, 谌利, 徐新福 (2005). 显性核不育油菜圆叶纯合两型系 GdlAB的选育. 中国农学通报 21, 174-175, 229.
14	王通强, 田筑萍, 黄泽素, 魏忠芬, 邵明波 (1999). 甘蓝型双低油菜细胞核显性雄性不育系黔油2AB的选育. 贵州农业科学 27, 14-18.
15	周熙荣, 庄静, 孙超才, 王伟荣, 李延莉, 杨立勇, 蒋美艳, 顾龙弟, 钱小芳 (2010). 甘蓝型油菜显性核不育纯合两型系“HY15AB”的选育. 上海农业学报 26, 1-4.
16	俎峰, 夏胜前, 顿小玲, 周正富, 曾芳琴, 易斌, 文静, 马朝芝, 沈金雄, 涂金星, 傅廷栋 (2010). 基于分子标记的油菜隐性核不育7-7365AB遗传模式探究. 中国农业科学 43, 3067-3075.
17	Cai CF, Zhu J, Lou Y, Guo ZL, Xiong SX, Wang K, Yang ZN (2015). The functional analysis of OsTDF1 reveals a conserved genetic pathway for tapetal development bet- ween rice and Arabidopsis.Sci Bull 60, 1073-1082.
18	Chalhoub B, Denoeud F, Liu SY, Parkin IAP, Tang HB, Wang XY, Chiquet J, Belcram H, Tong CB, Samans B, Corréa M, Silva CD, Just J, Falentin C, Koh CS, Clainche IL, Bernard M, Bento P, Noel B, Labadie K, Alberti A, Charles M, Arnaud D, Guo H, Daviaud C, Alamery S, Jabbari K, Zhao MX, Edger PP, Chelaifa H, Tack D, Lassalle G, Mestiri I, Schnel N, Paslier MCL, Fan GY, Renault V, Bayer PE, Golicz AA, Manoli S, Lee TH, Thi VHD, Chalabi S, Hu Q, Fan CC, Tollenaere R, Lu YH, Battail C, Shen JX, Sidebottom CHD, Wang XF, Canaguier A, Chauveau A, Bérard A, Deniot G, Guan M, Liu ZS, Sun FM, Lim YP, Lyons E, Town CD, Bancroft I, Wang XW, Meng JL, Ma JX, Pires JC, King GJ, Brunel D, Delourme R, Renard M, Aury JM, Adams KL, Batley J, Snowdon RJ, Tost J, Edwards D, Zhou YM, Hua W, Sharpe AG, Paterson AH, Guan CY, Wincker P (2014). Early allopolyploid evolution in the post-Neolithic Brassica napus oilseed genome. Science 345, 950-953.
19	Feng BM, Lu DH, Ma X, Peng YB, Sun YJ, Ning G, Ma H (2012). Regulation of the Arabidopsis anther transcriptome by DYT1 for pollen development.Plant J 72, 612-624.
20	Graybosch RA, Bernard RL, Cremeens CR, Palmer RG (1984). Genetic and cytological studies of a male-sterile, female-fertile soybean mutant, a new male-sterile gene (ms2) in Glycine max (L.) Merr.J Hered 75, 383-388.
21	Hird DL, Worrall D, Hodge R, Smartt S, Paul W, Scott R (1993). The anther-specific protein encoded by the Brassica napus and Arabidopsis thaliana A6 gene displays similarity to β-1, 3-glucanases.Plant J 4, 1023-1033.
22	Jiang LX, Yang SL, Xie LF, Puah CS, Zhang XQ, Yang WC, Sundaresan V, Ye D (2005). VANGUARD1 encodes a pectin methylesterase that enhances pollen tube growth in the Arabidopsis style and transmitting tract. Plant Cell 17, 584-596.
23	Li SF, Higginson T, Parish RW (1999). A novel MYB- related gene from Arabidopsis thaliana expressed in developing anthers.Plant Cell Physiol 40, 343-347.
24	Li SF, Iacuone S, Parish RW (2007). Suppression and restoration of male fertility using a transcription factor. Plant Biotechnol J 5, 297-312.
25	Liu SY, Liu YM, Yang XH, Tong CB, Edwards D, Parkin IAP, Zhao MX, Ma JX, Yu JY, Huang SM, Wang XY, Wang JY, Lu K, Fang ZY, Bancroft I, Yang TJ, Hu Q, Wang XF, Yue Z, Li HJ, Yang LF, Wu J, Zhou Q, Wang WX, King GJ, Pires JC, Lu CX, Wu ZY, Sampath P, Wang Z, Guo H, Pan SK, Yang LM, Min JM, Zhang D, Jin DC, Li WS, Belcram H, Tu JX, Guan M, Qi CQ, Du DZ, Li JN, Jiang LC, Batley J, Sharpe AG, Park BS, Ruperao P, Cheng F, Waminal NE, Huang Y, Dong CH, Wang L, Li JP, Hu ZY, Zhuang M, Huang Y, Huang JY, Shi JQ, Mei DS, Liu J, Lee TH, Wang JP, Jin HZ, Li ZY, Li X, Zhang JF, Xiao L, Zhou YM, Liu ZS, Liu XQ, Qin R, Tang X, Liu WB, Wang YP, Zhang YY, Lee J, Kim HH, Denoeud F, Xu X, Liang XM, Hua W, Wang XW, Wang J, Chalhoub B, Paterson AH (2014). The Brassica oleracea genome reveals the asymmetrical evolution of polyploid genomes.Nat Commun 5, 3930.
26	Lu PL, Chai MF, Yang JG, Ning G, Wang GL, Ma H (2014). The Arabidopsis CALLOSE DEFECTIVE MICROSPORE1 gene is required for male fertility through regulating callose metabolism during microsporogenesis.Plant Physiol 164, 1893-1904.
27	McCormick S (2004). Control of male gametophyte develop- ment.Plant Cell 16, 142-153.
28	Pabo CO, Sauer RT (1992). Transcription factors: structural families and principles of DNA recognition.Annu Rev Biochem 61, 1053-1095.
29	Parish RW, Li SF (2010). Death of a tapetum: a programme of development altruism.Plant Sci 178, 73-89.
30	Phan HA, Iacuone S, Li SF, Parish RW (2011). The MYB80 transcription factor is required for pollen development and the regulation of tapetal programmed cell death in Arabidopsis thaliana. Plant Cell 23, 2209-2224.
31	Phan HA, Li SF, Parish RW (2012). MYB80, a regulator of tapetal and pollen development, is functionally conserved in crops. Plant Mol Biol 78, 171-183.
32	Sorensen AM, Kröber S, Unte US, Huijser P, Dekker K, Saedler H (2003). The Arabidopsis ABORTED MICROSPORES (AMS) gene encodes a MYC class transcription factor.Plant J 33, 413-423.
33	Wang XW, Wang HZ, Wang J, Sun RF, Wu J, Liu SY, Bai YQ, Mun JH, Bancroft I, Cheng F, Huang SW, Li XX, Hua W, Wang JY, Wang XY, Freeling M, Pires JC, Paterson AH, Chalhoub B, Wang B, Hayward A, Sharpe AG, Park BS, Weisshaar B, Liu BH, Li B, Liu B, Tong CB, Song C, Duran C, Peng CF, Geng CY, Koh C, Lin CY, Edwards D, Mu DS, Shen D, Soumpourou E, Li F, Fraser F, Lassalle G, King GJ, Bonnema G, Tang HB, Wang HP, Belcram H, Zhou HL, Hirakawa H, Abe H, Guo H, Wang H, Jin HZ, Parkin IAP, Batley J, Kim JS, Just J, Li JW, Xu JH, Deng J, Kim JA, Li JP, Yu JY, Meng JL, Wang JP, Min JM, Poulain J, Wang J, Hatakeyama K, Wu K, Wang L, Fang L, Trick M, Links MG, Zhao MX, Jin M, Ramchiary N, Drou N, Berkman PJ, Cai QL, Huang QF, Li RQ, Tabata S, Cheng SF, Zhang S, Zhang SJ, Huang SM, Sato S, Sun SL, Kwon SJ, Choi SR, Lee TH, Fan W, Zhao X, Tan X, Xu X, Wang Y, Qiu Y, Yin Y, Li YR, Du YC, Liao YC, Lim Y, Narusaka Y, Wang YP, Wang ZY, Li ZY, Wang ZW, Xiong ZY, Zhang ZH (2011). The genome of the mesopolyploid crop species Brassica rapa. Nat Genet 43, 1035-1039.
34	Wilson ZA, Morroll SM, Dawson J, Swarup R, Tighe PJ (2001). The Arabidopsis MALE STERILITY (MS1) gene is a transcriptional regulator of male gametogenesis, with homology to the PHD-finger family of transcription factors. Plant J 28, 27-39.
35	Xu Y, Lacuone S, Li SF, Parish RW (2014). MYB80 homo- logues in Arabidopsis, cotton and Brassica: regulation and functional conservation in tapetal and pollen development.BMC Plant Biol 14, 278.
36	Zhang S, Fang ZJ, Zhu J, Gao JF, Yang ZN (2010). OsMYB103 is required for rice anther development by regulating tapetum development and exine formation.Sci Bull 55, 3288-3297.
37	Zhang W, Sun Y, Timofejeva L, Chen CB, Grossniklaus U, Ma H (2006). Regulation of Arabidopsis tapetum development and function by DYSFUNCTIONAL TAPET- UM1 (DYT1) encoding a putative bHLH transcription factor.Development 133, 3085-3095.
38	Zhang ZB, Zhu J, Gao JF, Wang C, Li H, Li H, Zhang HQ, Zhang S, Wang DM, Wang QX, Huang H, Xia HJ, Yang ZN (2007). Transcription factor AtMYB103 is required for anther development by regulating tapetum development, callose dissolution and exine formation in Arabidopsis.Plant J 52, 528-538.
39	Zhu J, Chen H, Li H, Gao JF, Jiang H, Wang C, Guan YF, Yang ZN (2008). Defective in Tapetal Development and Function 1 is essential for anther development and tapetal function for microspore maturation in Arabidopsis.Plant J 55, 266-277.

Gene name	Gene ID	Chromosome	Length (aa)	MW (kDa)	pI	Instability	Aliphatic index	Gravy
BrMYB80A02	103851848	A02	320	36.1054	6.95	35.89	65.88	-0.808
BrMYB80A10	103845046	A10	320	35.8452	7.24	33.15	69.81	-0.721
BolMYB80C02	106327859	C02	324	36.5430	7.75	37.04	66.57	-0.790
BolMYB80C09	106317148	C09	320	35.9113	7.22	31.94	68.56	-0.740
BnMYB80A02	106389601	A02	322	36.3678	6.95	35.55	65.47	-0.792
BnMYB80A10	674915774	A10	320	35.8232	7.24	34.62	68.59	-0.712
BnMYB80C02	106379735	C02	320	35.9113	7.22	31.94	68.56	-0.740
BnMYB80C03	106385056	C03	320	35.9113	7.22	31.94	68.56	-0.740
BnMYB80C05	106400365	C05	319	35.7842	6.90	33.76	68.50	-0.738
BnMYB80Cnn	106389601	Cnn	324	36.5490	6.93	35.65	66.57	-0.771

Gene name	Gene ID	Chromosome	Length (aa)	MW (kDa)	pI	Instability	Aliphatic index	Gravy
BrMYB80A02	103851848	A02	320	36.1054	6.95	35.89	65.88	-0.808
BrMYB80A10	103845046	A10	320	35.8452	7.24	33.15	69.81	-0.721
BolMYB80C02	106327859	C02	324	36.5430	7.75	37.04	66.57	-0.790
BolMYB80C09	106317148	C09	320	35.9113	7.22	31.94	68.56	-0.740
BnMYB80A02	106389601	A02	322	36.3678	6.95	35.55	65.47	-0.792
BnMYB80A10	674915774	A10	320	35.8232	7.24	34.62	68.59	-0.712
BnMYB80C02	106379735	C02	320	35.9113	7.22	31.94	68.56	-0.740
BnMYB80C03	106385056	C03	320	35.9113	7.22	31.94	68.56	-0.740
BnMYB80C05	106400365	C05	319	35.7842	6.90	33.76	68.50	-0.738
BnMYB80Cnn	106389601	Cnn	324	36.5490	6.93	35.65	66.57	-0.771

Gene name	CDS (bp)	Exon	MYB80 conserved domain (aa)
Gene name	CDS (bp)	Exon	SANT	SANT	IRO	KNOX1	Cir_N
BrMYB80A02	1772	3	13-63	66-114	-	-	-
BrMYB80A10	1631	3	13-63	66-114	-	-	-
BolMYB80C02	1891	4	13-63	66-114	123-140	130-173	246-282
BolMYB80C09	1573	3	13-63	66-114	123-140	130-173	-
BnMYB80A02	1653	3	13-63	66-114	123-140	130-173	244-280
BnMYB80A10	1471	3	13-63	66-114	123-140	130-173	-
BnMYB80C02	1471	3	13-63	66-114	123-140	130-173	-
BnMYB80C03	1471	3	13-63	66-144	123-140	130-173	-
BnMYB80C05	1461	3	13-63	66-144	123-140	130-173	-
BnMYB80Cnn	1668	3	13-63	66-144	123-140	130-173	246-282

Gene name	CDS (bp)	Exon	MYB80 conserved domain (aa)
Gene name	CDS (bp)	Exon	SANT	SANT	IRO	KNOX1	Cir_N
BrMYB80A02	1772	3	13-63	66-114	-	-	-
BrMYB80A10	1631	3	13-63	66-114	-	-	-
BolMYB80C02	1891	4	13-63	66-114	123-140	130-173	246-282
BolMYB80C09	1573	3	13-63	66-114	123-140	130-173	-
BnMYB80A02	1653	3	13-63	66-114	123-140	130-173	244-280
BnMYB80A10	1471	3	13-63	66-114	123-140	130-173	-
BnMYB80C02	1471	3	13-63	66-114	123-140	130-173	-
BnMYB80C03	1471	3	13-63	66-144	123-140	130-173	-
BnMYB80C05	1461	3	13-63	66-144	123-140	130-173	-
BnMYB80Cnn	1668	3	13-63	66-144	123-140	130-173	246-282

Gene name	α helix (%)	Extend strand (%)	β turn (%)	Random coil (%)
BrMYB80A02	41.25	11.56	10.00	37.19
BrMYB80A10	37.81	14.06	10.00	38.12
BolMYB80C02	44.14	10.19	8.64	37.04
BolMYB80C09	35.94	15.31	10.94	37.81
BnMYB80A02	42.55	11.18	9.63	36.65
BnMYB80A10	37.19	15.00	10.31	37.50
BnMYB80C02	35.94	15.31	10.94	37.81
BnMYB80C03	35.94	15.31	10.94	37.81
BnMYB80C05	36.68	14.73	10.03	38.56
BnMYB80Cnn	44.14	10.49	9.57	35.80
