Cloning and Functional Analysis of APETALA3/DEFICIENS Homologous Gene from Rhus chinensis

doi:10.11983/CBB24015

Abstract

Abstract: The APETALA3/DEFICIENS (AP3/DEF) gene is a B-class gene of the MADS-box gene family, which is mainly involved in the regulation of petal and stamen development during flower development. Cloning and analysis of the AP3/DEF homologous genes from Rhus chinensis can help exploring their role in the development of stamen. The CDS of AP3/DEF homologous gene was obtained using RT-PCR; its sequence and structural domains were compared and analyzed by NCBI CD Search; interactions between AP3/DEF homologous proteins and other MADS-box transcription factors in R. chinensis were verified by using yeast two-hybrid system; real-time fluorescence PCR was used to analyze the spatial and temporal expression patterns of the AP3/DEF homologous genes; overexpression in Arabidopsis was conducted to verify the function of the AP3/DEF homologous genes in flower organ development. Two coding sequences of AP3/ DEF homologous genes in R. chinensis were cloned and named RcAP3 (GenBank: OR962160) and RcTM6 (GenBank: OR962159). Based on the alignment of their conserved amino acid domains and phylogenetic analysis, these two protein sequences showed the closest genetic relationship to the AP3/DEF homologous gene-encoded proteins in the Anacardiaceae family, including Mangifera indica and Pistacia vera. The yeast two-hybrid results showed that RcAP3 and RcTM6 interacted with the B-class protein RcPI, the C-class proteins RcAG and Rcag in R. chinensis, but not with the A-class and E-class proteins. Real-time fluorescence quantification results demonstrated that RcAP3 and RcTM6 were highly expressed during the rapid growth stage of flower buds in different sexes of R. chinensis, with lower expression levels during the early bud development and after flowering. RcAP3 exhibited high expression levels during buds differentiation in female, male, and hermaphrodite flowers, while RcTM6 showed significant expression in hermaphrodite flowers and very low expression in male and female flowers. During the rapid growth stage of hermaphrodite flowers, RcAP3 was highly expressed in both petals and stamens with minimal differences, whereas RcTM6 showed significantly higher expression in stamens compared to other floral organs. RcAP3 could restore the petal and stamen phenotypes in the ap3-3 mutant of Arabidopsis, while overexpression of RcTM6 resulted in shortened petals, stamens, and aborted ovaries in Arabidopsis. Functional differentiation exists between the AP3/DEF subfamily homologous genes, RcAP3 and RcTM6. RcAP3 promotes petal and stamen development, while RcTM6 inhibits stamen development. These findings provide a foundation for further research on the molecular mechanisms underlying sex differentiation in R. chinensis.

Key words: Rhus chinensis, RcAP3, RcTM6, expression pattern, functional analysis

Lei Gu, Qi Zhang, Xia Zhang, Bingbing Yang, Fanglan Wang, Wen Liu, Faju Chen. Cloning and Functional Analysis of APETALA3/DEFICIENS Homologous Gene from Rhus chinensis[J]. Chinese Bulletin of Botany, 2024, 59(4): 533-543.

Add to citation manager EndNote|Ris|BibTeX

URL: https://www.chinbullbotany.com/EN/10.11983/CBB24015

https://www.chinbullbotany.com/EN/Y2024/V59/I4/533

Figures/Tables 10

References 33

[1]	Broholm SK, Pöllänen E, Ruokolainen S, Tähtiharju S, Kotilainen M, Albert VA, Elomaa P, Teeri TH (2010). Functional characterization of B class MADS-box transcription factors in Gerbera hybrida. J Exp Bot 61, 75-85. DOI PMID
[2]	Cao X, Liu XY, Wang XT, Yang MX, van Giang T, Wang J, Liu XL, Sun S, Wei K, Wang XX, Gao JC, Du YC, Qin Y, Guo YM, Huang ZJ (2019). B-class MADS-box TM6 is a candidate gene for tomato male sterile-15²⁶. Theor Appl Genet 132, 2125-2135.
[3]	Causier B, Castillo R, Xue Y, Schwarz-Sommer Z, Davies B (2010). Tracing the evolution of the floral homeotic B- and C-function genes through genome synteny. Mol Biol Evol 27, 2651-2664. DOI PMID
[4]	Clough SJ, Bent AF (1998). Floral dip: a simplified method for Agrobacterium-mediated transformation of Arabidopsis thaliana. Plant J 16, 735-743. DOI PMID
[5]	de Martino G, Pan I, Emmanuel E, Levy A, Irish VF (2006). Functional analyses of two tomato APETALA3 genes demonstrate diversification in their roles in regulating floral development. Plant Cell 18, 1833-1845. DOI PMID
[6]	Doyle JJ (1994). Evolution of a plant homeotic multigene family: toward connecting molecular systematics and molecular developmental genetics. Syst Biol 43, 307-328.
[7]	Fang ZW, Qi R, Li XF, Liu ZX (2014). Ectopic expression of FaesAP3, a Fagopyrum esculentum (Polygonaceae) AP3 orthologous gene rescues stamen development in an Arabidopsis ap3mutant. Gene 550, 200-206.
[8]	Goto K, Meyerowitz EM (1994). Function and regulation of the Arabidopsis floral homeotic gene PISTILLATA. Genes Dev 8, 1548-1560.
[9]	Hernández-Hernández T, Martínez-Castilla LP, Alvarez- Buylla ER (2007). Functional diversification of B MADS- box homeotic regulators of flower development: adaptive evolution in protein-protein interaction domains after major gene duplication events. Mol Biol Evol 24, 465-481. PMID
[10]	Jack T, Brockman LL, Meyerowitz EM (1992). The homeotic gene APETALA3 of Arabidopsis thaliana encodes a MADS box and is expressed in petals and stamens. Cell 68, 683-697. DOI PMID
[11]	Jing DL, Chen WW, Shi M, Wang D, Xia Y, He Q, Dang JB, Guo QG, Liang GL (2020). Ectopic expression of an Eriobotrya japonica APETALA3 ortholog rescues the petal and stamen identities in Arabidopsis ap3-3 mutant. Biochem Biophys Res Commun 523, 33-38.
[12]	Jing DL, Xia Y, Zhang SG, Wang JH (2016). Expression analysis of B-class MADS-box genes from Catalpa speciosa. Chin Bull Bot 51, 210-217. (in Chinese)
	景丹龙, 夏燕, 张守攻, 王军辉 (2016). 黄金树B类MADS- box基因表达特征分析. 植物学报 51, 210-217. DOI
[13]	Kim S, Yoo MJ, Albert VA, Farris JS, Soltis PS, Soltis DE (2004). Phylogeny and diversification of B-function MADS- box genes in angiosperms: evolutionary and functional implications of a 260-million-year-old duplication. Am J Bot 91, 2102-2118.
[14]	Kramer EM, Irish VF (2000). Evolution of the petal and stamen developmental programs: evidence from comparative studies of the lower eudicots and basal angiosperms. Int J Plant Sci 161, S29-S40.
[15]	Lai XL, Daher H, Galien A, Hugouvieux V, Zubieta C (2019). Structural basis for plant MADS transcription factor oligomerization. Comput Struct Biotechnol J 17, 946- 953.
[16]	Lamb RS, Irish VF (2003). Functional divergence within the APETALA3/PISTILLATA floral homeotic gene lineages. Proc Natl Acad Sci USA 100, 6558-6563.
[17]	Li B, Gao JY, Gong LM, Liu PA, Li SX (2015). Chemical constituents from Rhus chinensis fruit dregs. J Chin Medi Materials 38, 1209-1211. (in Chinese)
	李斌, 高洁莹, 龚力民, 刘平安, 李顺祥 (2015). 盐肤木果粕化学成分研究. 中药材 38, 1209-1211.
[18]	Li MC, Wang AD, Zhang YQ, Han TT, Guan L, Fan DX, Liu JY, Xu YN (2022). A comprehensive review on ethnobotanical, phytochemical and pharmacological aspects of Rhus chinensis Mill. J Ethnopharmacol 293, 115288.
[19]	Li XF, Xu J, Yang R, Jia LY, Deng XJ, Xiong LJ, Zhang XP, Fang Q, Zhang W, Sun Y, Xu L (2013). Analysis of B-class genes NAP3L3 and NAP3L4 in Narcissus tazetta var. chinensis. Plant Mol Biol Rep 31, 255-263.
[20]	Litt A, Kramer EM (2010). The ABC model and the diversification of floral organ identity. Semin Cell Dev Biol 21, 129-137. DOI PMID
[21]	Livak KJ, Schmittgen TD (2001). Analysis of relative gene expression data using real-time quantitative PCR and the 2^-∆∆CTmethod. Methods 25, 402-408. DOI PMID
[22]	Ma N, Cai SB, Sun YL, Chu CQ (2024). Chinese sumac (Rhus chinensis Mill.) fruits prevent hyperuricemia and uric acid nephropathy in mice fed a high-purine yeast diet. Nutrients 16, 184.
[23]	Poupin MJ, Federici F, Medina C, Matus JT, Timmermann T, Arce-Johnson P (2007). Isolation of the three grape sub-lineages of B-class MADS-box TM6, PISTILLATA and APETALA3 genes which are differentially expressed during flower and fruit development. Gene 404, 10-24.
[24]	Rijpkema AS, Royaert S, Zethof J, van der Weerden G, Gerats T (2006). Analysis of the Petunia TM6 MADS box gene reveals functional divergence within the DEF/AP3 lineage. Plant Cell 18, 1819-1832. PMID
[25]	Rusanov K, Kovacheva N, Rusanova M, Linde M, Debener T, Atanassov I (2019). Genetic control of flower petal number in Rosa × Damascena Mill f. trigintipetala. Biotechnol Biotec Eq 33, 597-604.
[26]	Shen GX, Jia Y, Wang WL (2021). Evolutionary divergence of motifs in B-class MADS-box proteins of seed plants. J Biol Res-Thessalon 28, 12.
[27]	Shen GX, Yang CH, Shen CY, Huang KS (2019). Origination and selection of ABCDE and AGL6 subfamily MADS- box genes in gymnosperms and angiosperms. Biol Res 52, 25.
[28]	Sommer H, Beltrán JP, Huijser P, Pape H, Lönnig WE, Saedler H, Schwarz-Sommer Z (1990). Deficiens, a homeotic gene involved in the control of flower morphogenesis in Antirrhinum majus: the protein shows homolo-gy to transcription factors. EMBO J 9, 605-613. DOI PMID
[29]	Sun FH, Fang HY, Wen XH, Zhang LS (2023). Phylogenetic and expression analysis of MADS-box gene family in Rhododendron ovatum. Chin Bull Bot 58, 404-416. (in Chinese)
	孙福辉, 方慧仪, 温小蕙, 张亮生 (2023). 马银花MADS- box基因家族系统进化与表达分析. 植物学报 58, 404-416. DOI
[30]	Vandenbussche M, Zethof J, Royaert S, Weterings K, Gerats T (2004). The duplicated B-class heterodimer model: whorl-specific effects and complex genetic interactions in Petunia hybrida flower development. Plant Cell 16, 741-754. DOI PMID
[31]	Ye A, Zhang CL, Sun YL, Wang WN, He YH, Bao MZ (2017). Characterization and functional analysis of five MADS-Box B class genes related to floral organ identification in Tagetes erecta. PLoS One 12, e0169777.
[32]	Zhang HQ, Han W, Linghu T, Zhao ZX, Wang AZ, Zhai R, Yang CQ, Xu LF, Wang ZG (2023). Overexpression of a pear B-class MADS-box gene in tomato causes male sterility. Fruit Res 3, 1.
[33]	Zhang Q, Wang BG, Duan K, Wang LG, Wang M, Tang XM, Pan AH, Sui SZ, Wang GD (2011). The paleoAP3-type gene CpAP3, an ancestral B-class gene from the basal angiosperm Chimonanthus praecox, can affect stamen and petal development in higher eudicots. Dev Genes Evol 221, 83-93.

Primers	Primer sequence (5'-3')	Primer usage
RcAP3-CDS-F	ATGGCTCGAGGAAAGATCCAG	CDS cloning and positive plant identification
RcAP3-CDS-R	CTAGTCAAGCAAGGGGGAGG
RcTM6-CDS-F	ATGGGTCGCGGAAAGATTG
RcTM6-CDS-R	TCAACCAAGGCTGAGATTGTTG
qRcAP3-CDS-F	GAAGAAGGTAAGGAGTGTGACAG	Real-time fluorescent quantitative PCR
qRcAP3-CDS-R	AGGTGGTGAGATCTGAGCCTG
qRcTM6-CDS-F	CGTCCGTGAAAGAAAGTACCATG
qRcTM6-CDS-R	GCGTACAGGTTAGATGCTCC
qPP2A-F	TCCACCGTCCGATCATCAGAAC	Reference gene
qPP2A-R	GCACGTTCCATTCCTCCACC	Reference gene
ap3-jianceF1	ATGGCGAGAGGGAAGATCC	Detection of ap3 gene-pure plants in Arabidopsis thaliana
ap3-jianceR1	GATCAAGAGGATAGAGAACCAGACAAACAGA
ap3-jianceF2	ACAGTTTCCTCTTGGTTTCTTGC
ap3-jianceR2	CGCATCAAGAATTTAACCAACCAGCG

Primers	Primer sequence (5'-3')	Primer usage
RcAP3-CDS-F	ATGGCTCGAGGAAAGATCCAG	CDS cloning and positive plant identification
RcAP3-CDS-R	CTAGTCAAGCAAGGGGGAGG
RcTM6-CDS-F	ATGGGTCGCGGAAAGATTG
RcTM6-CDS-R	TCAACCAAGGCTGAGATTGTTG
qRcAP3-CDS-F	GAAGAAGGTAAGGAGTGTGACAG	Real-time fluorescent quantitative PCR
qRcAP3-CDS-R	AGGTGGTGAGATCTGAGCCTG
qRcTM6-CDS-F	CGTCCGTGAAAGAAAGTACCATG
qRcTM6-CDS-R	GCGTACAGGTTAGATGCTCC
qPP2A-F	TCCACCGTCCGATCATCAGAAC	Reference gene
qPP2A-R	GCACGTTCCATTCCTCCACC	Reference gene
ap3-jianceF1	ATGGCGAGAGGGAAGATCC	Detection of ap3 gene-pure plants in Arabidopsis thaliana
ap3-jianceR1	GATCAAGAGGATAGAGAACCAGACAAACAGA
ap3-jianceF2	ACAGTTTCCTCTTGGTTTCTTGC
ap3-jianceR2	CGCATCAAGAATTTAACCAACCAGCG

Species	Protein	GenBank ID
Rhus chinensis	RcAP3	OR962159
R. chinensis	RcTM6	OR962160
Nicotiana tabacum	NtDEF	CAA65288
Petunia × hybrida	PhDEF	AAQ72510
Solanum lycopersicum	SolyDEF	CAJ53871
Antirrhinum majus	AmDEF	P23706
Torenia fournieri	TofoDEF	BAG24492
Gerbera hybrid	GDEF2	CAA08803
Arabidopsis thaliana	AtAP3	NP_191002
Pistacia vera	PvAP3	OR962159
Mangifera indica	MinAP3	XP_044510378
Lotus japonicus	LojaAP3	AAX13301
Gongora galeata	GogaDEF	ACR16038
Oncidium hybrid	OMADS9	ADJ67235
Dendrobium crumenatum	DecrAP3	AAZ95249
Spiranthes odorata	SpodDEF	ACR16049
Vanilla planifolia	VaplDEF	ACR16055
Asparagus officinalis	AODEF	BAC75969
Muscari armeniacum	MaDEF	BAE48147
Tulipa gesneriana	TGDEFA	BAC75970
T. gesneriana	TGDEFB	BAC75971
Lilium longiflorum	LMADS1	AAM27456
Monotropa hypopitys	MhTM6	AQM52303
Tradescantia ohiensis	TrohDEF	BAD80745
Commelina communis	CocoAP3	BAD80747
Oryza sativa	OsMADS16	Q944S9
Chimonanthus praecox	ChprAP3	ABK34952
Akebia trifoliata	AktAP3-1	AAT46097
Hydrangea macrophylla	HmTM6	AAF73932
Petunia × hybrida	PhTM6	AAS46017
Helianthus annuus	HAM91	AAO18231
Rosa rugosa	MASAKO B3	BAB63261
Prunus avium	PaTM6	BAT57494
Malus domestica	MdTM6	BAC11907
Ma. domestica	MdMADS13	CAC80856
Pistacia vera	PvTM6	XP_031264419
Mangifera indica	MinTM6	XP_044469431
Philadelphus pubescens	PhpTM6	ACY08886
Vitis vinifera	VvTM6	ABI98021
Saurauia zahlbruckneri	SzTM6	ACY08897
Actinidia chinensis	AcAP3	ADU15473
Ar. thaliana	AtPI	NP_197524

Species	Protein	GenBank ID
Rhus chinensis	RcAP3	OR962159
R. chinensis	RcTM6	OR962160
Nicotiana tabacum	NtDEF	CAA65288
Petunia × hybrida	PhDEF	AAQ72510
Solanum lycopersicum	SolyDEF	CAJ53871
Antirrhinum majus	AmDEF	P23706
Torenia fournieri	TofoDEF	BAG24492
Gerbera hybrid	GDEF2	CAA08803
Arabidopsis thaliana	AtAP3	NP_191002
Pistacia vera	PvAP3	OR962159
Mangifera indica	MinAP3	XP_044510378
Lotus japonicus	LojaAP3	AAX13301
Gongora galeata	GogaDEF	ACR16038
Oncidium hybrid	OMADS9	ADJ67235
Dendrobium crumenatum	DecrAP3	AAZ95249
Spiranthes odorata	SpodDEF	ACR16049
Vanilla planifolia	VaplDEF	ACR16055
Asparagus officinalis	AODEF	BAC75969
Muscari armeniacum	MaDEF	BAE48147
Tulipa gesneriana	TGDEFA	BAC75970
T. gesneriana	TGDEFB	BAC75971
Lilium longiflorum	LMADS1	AAM27456
Monotropa hypopitys	MhTM6	AQM52303
Tradescantia ohiensis	TrohDEF	BAD80745
Commelina communis	CocoAP3	BAD80747
Oryza sativa	OsMADS16	Q944S9
Chimonanthus praecox	ChprAP3	ABK34952
Akebia trifoliata	AktAP3-1	AAT46097
Hydrangea macrophylla	HmTM6	AAF73932
Petunia × hybrida	PhTM6	AAS46017
Helianthus annuus	HAM91	AAO18231
Rosa rugosa	MASAKO B3	BAB63261
Prunus avium	PaTM6	BAT57494
Malus domestica	MdTM6	BAC11907
Ma. domestica	MdMADS13	CAC80856
Pistacia vera	PvTM6	XP_031264419
Mangifera indica	MinTM6	XP_044469431
Philadelphus pubescens	PhpTM6	ACY08886
Vitis vinifera	VvTM6	ABI98021
Saurauia zahlbruckneri	SzTM6	ACY08897
Actinidia chinensis	AcAP3	ADU15473
Ar. thaliana	AtPI	NP_197524

Parameter	RcAP3	RcTM6
Formula	C₁₁₁₈H₁₈₂₄N₃₂₈O₃₄₈S₅	C₁₁₂₅H₁₇₈₉N₃₂₅O₃₄₃S₆
Molecular mass (kDa)	25.59	25.55
Total number of atoms	3623	3588
Theoretical pI	9.23	9.33
Total number of negatively char- ged residues (Asp+Glu)	30	29
Total number of positively char- ged residues (Arg+Lys)	35	36
Instability index	48.17	40.95
Aliphatic index	86.82	73.50
Grand average of hydropathicity	-0.754	-0.749
Signal peptide	None	None
Transmembrane domain	None	None
